Electrically Heated or Gas Fired

bell furnacesUpton manufactures lift off bell type furnaces in either electric or gas fired heating systems. The design of the heating systems provide for shielding of the loads from the detrimental effects of direct radiant heat or flame impingement while promoting efficient uniform heating of the loads.

Electric Heating Systems

Electric furnaces employ various styles of resistance type electric heaters to maintain the integrity of the furnace atmospheres and thermal efficiencies. Heaters can be supplied as either standard open resistance wire type, or bayonet/radiant tube style based on the specific furnace application, intended atmosphere and/or customer preference. SCR power controllers with control panel door mounted diagnostics displays are standard for Upton furnaces, with optional PLC and PC systems integration available. Heating systems are factory prewired to meet NEC and NFPA standards, and all equipment is factory tested prior to shipment.

Gas Firing Systems

Gas fired furnaces employ either direct gas firing or radiant tube style gas firing burners to maintain the integrity of the furnace atmosphere. Sealed burner systems can be supplied as either standard tube firing or single end recuperative type based upon customer preference. Solid state flame supervision systems with panel door mounted diagnostics displays are standard for Upton furnaces, with optional PLC and PC systems integration available. Combustions systems are factory prepiped to meet FM, IRI, and NFPA standards where applicable, and all equipment is factory tested prior to shipment.

Thermal Recirculation Systems

Upton furnaces utilize alloy construction cartridge type fans for recirculation of the furnace atmosphere, promoting close tolerance temperature uniformities. Recirculation fans are located within a stainless steel plenum positioned in the top of the furnace heating chamber, integrated with the gas firing or electric heating system, to eliminate potential of direct heating of the workloads. Lateral sidewall ductwork is employed for introduction of the furnace atmosphere into the workzone beneath the workload, with recirculation and redistribution through the fan plenum inlet.

Electro/Mechanical Type Lifting System

Upton lift off type furnaces employ a rigid floor loading superstructure design with positive guides for smooth operation. The lifting mechanism is designed with an electro/mechanical type system utilizing ball screw actuators.

Custom Designed & Engineered

Our in-house engineering and manufacturing allows Upton to custom design furnaces and systems to a customers process and specification requirements, rather than attempting to provide to you standard pre-design equipment, as some of our competitors would attempt to do. Follow-up technical services are available for all Upton thermal process systems.

Our Engineered Thermal Solutions will allow for flexibility in your manufacturing productivity.
